Pocket Penetrometer

  • Model: G-128-29-3729
  • Manufactured by: ELE International


Ask a question




Product Description:
  • Direct-reading scale in tons/sq. ft. and kg/sq. cm.
  • Ground and polished stainless steel loading piston.
  • Calibrated spring and penetrometer body plated for rust
    resistance and long life.'
  • Convenient belt-loop style carrying case.
  • Optional Adapter Foot for testing very soft materials.

The Pocket Penetrometer was originally developed for use by field personnel in checking visual classification of soils. Data was compiled on several thousand unconfined compressive strength tests of silty clays and clayey soils against the penetrometer readings to develop the scale.A close relationship exists between the penetrometer's scale reading and soil type.

Specifications

Range.0.25 to 4.5 tons/sq. ft. (kg/sq. cm).
Scale Divisions0.25 tons/sq. ft. (kg/sq. cm)
Load Piston1/4" (6 mm) diam.; stainless steel
Carrying CaseCanvas; belt-loop style
Dimensions3/4" diam. x 6-3/8" l. (19 x 162 mm).
WeightNet 7 oz. (198 g)


Ordering Information
Note: Shown with Adapter Foot; not included, order separately.
EI29-3729.

Accessories
EI29-3729/10. Adapter Foot. 1" (25.4 mm) diam. Increases piston area 16 times for testing on soft materials.

Special Note:
The Pocket Penetrometer does not replace field and laboratory testing analysis.
